2025 Best Price T50 40ft LPG Storage Tank

2025 Best Price T50 40ft LPG Storage Tank
2025 Best Price T50 40ft LPG Storage Tank 2025 Best Price T50 40ft LPG Storage Tank 2025 Best Price T50 40ft LPG Storage Tank 2025 Best Price T50 40ft LPG Storage Tank

Большие изображения :  2025 Best Price T50 40ft LPG Storage Tank

Подробная информация о продукте:
Place of Origin: CHINA
Фирменное наименование: GNEE
Сертификация: SGS
Оплата и доставка Условия:
Minimum Order Quantity: ≥1sets
Цена: depends on the product
Delivery Time: Transit time: Est. 17-24 days
Payment Terms: L/C,D/A,D/P,MoneyGram,Western Union,T/T

2025 Best Price T50 40ft LPG Storage Tank

описание
Inner Cylinder Material: Q345R Condition: new
Outer Vessel Material: Carbon Steel Key Selling Points: Long Service Life
Keywords: lng storage tank for sale Geometric Volume: 10.520m3
Fluid: LNG, LOX, LIN, LAR, LCO2, etc. Working Years Design: 20years
Выделить:

40ft LPG storage tank

,

T50 cryogenic storage tank

,

LPG tank with warranty

2025 Best Price T50 40ft LPG Storage Tank
Product Attributes
Attribute Value
Inner Cylinder Material Q345R
Condition New
Outer Vessel Material Carbon Steel
Key Selling Points Long Service Life
Keywords LNG storage tank for sale
Geometric Volume 10.520m³
Fluid LNG, LOX, LIN, LAR, LCO₂, etc.
Working Years Design 20 years
Product Description

LPG gas storage tanks are professional products for storing LPG gas. LPG gas storage tanks are special equipment, Class III pressure vessels, and are made of 06Ni9DR materials. LPG gas storage tanks are manufactured through flaw detection, water pressure and air pressure tests, on-site inspections by the Technical Supervision Bureau, and pressure vessel inspection certificates are issued. External rust removal and painting are also required. Liquefied gas storage tanks have strict quality appraisals for the material of pressure components, appearance dimensions and weld quality, operation quality, installation quality, internal devices, and safety accessories.

Specification
Capacity of LPG Tank 5m³
Orientation of LPG Tank Horizontal Single Layer LPG TANK
Design Pressure 1.77MPa
Working Pressure 1.63MPa
Working Temperature -19~50℃
Medium LPG (Propane)
Heat Treatment Post-weld heat treatment for LPG Tank
Design, Manufacturing and Inspection Standard ISO/CE/ASME for LPG TANK
Detailed Specifications
Volume (m³) Nominal Diameter (mm) Thickness (mm) Weight (kg) External Dimensions Length × Width × Height (mm)
10 1600 10 10 3000 3990 5260×1620×2870
12 1800 10 10 3300 4788 5030×1820×3070
15 1800 10 10 3860 5985 6260×1820×3070
20 2200 12 12 5020 7980 5654×2224×3470
25 2200 12 12 6100 9975 7004×2224×3470
32 2400 14 14 7985 12768 7588×2428×3760
40 2700 14 16 9720 15960 7472×2728×3973
45 2700 14 16 10440 17955 8342×2728×3973
50 2200 12 14 6020 9975 7088×2224×2814
50 2300 12 14 7110 12768 8158×2324×2914
60 2400 14 14 7710 12768 7508×2428×3018
65 2300 12 14 8630 15960 10400×2324×2914
80 2400 14 14 9380 15960 9270×2428×3018
45 2700 14 16 10220 17965 8342×2728×3318
50 2600 14 16 11325 19950 9908×2628×3890
50 2700 14 16 11325 19950 9182×2728×3990
60 2700 14 16 13035 23940 10962×2728×3990
65 2700 14 16 13895 25935 11832×2728×3990
80 2800 16 16 17840 31920 13512×2832×4090
2025 Best Price T50 40ft LPG Storage Tank 0 2025 Best Price T50 40ft LPG Storage Tank 1 2025 Best Price T50 40ft LPG Storage Tank 2
Working with LPG Tanks

The following safety measures are recommended when working with LPG tanks:

  • It's advisable to install a LPG bulk tank in a well-ventilated or outdoor area and at ground level. Mechanical ventilation systems should be considered to guarantee the provision of fresh air.
  • LPG tanks must be protected against any source of ignition or heat and incorporate a fire-resistance rating. Combustible materials should also be kept away from LPG tanks, as well as anything that may potentially generate static electricity.
  • These installations should be located far away from incompatible substances and barrier systems should be considered (for instance, a screen wall made from non-combustible materials).
  • Alarm systems and air-quality testing are recommended to monitor potential LPG leakages.
  • Staff must wear adequate PPE when manipulating LPG tanks to avoid freezer burns and other hazards.
  • Correct maintenance programs must be guaranteed to avoid tank bursts and other safety issues.
  • Pressure-relief valves are common accessories for a LP gas cylinder. These can help release pressure in case a pressure build-up endangers the system.
  • The engineering team in charge of designing and implementing LPG tanks must follow the required national and international legislation and quality protocols.
  • LPG tanks must be stored in a vertical position with valves closed. The use of appropriate restraining methods must also be considered, including chains or safety straps.
  • These storage solutions must also keep all necessary documentation registering the safety measures that have been undertaken, as well as all documentation related to dangerous goods protocols.
